HEAT SHRINKABLE SLEEVES

HEAT SHRINKABLE SLEEVES

(For LT application, 160-170 Microns, Di-Electric Strength 2.5 to 5KV, Shrinkage 25% at 150oC)

S.No. Layflat Size Suitable for Busbar
Sizes (MM)		 Rate per Mt. Std. Roll
1 15 6x4, 6x6 7.90 50 Mt.
2 17 10x3 7.90 50 Mt.
3 20 10x6, 12x3 7.50 50 Mt.
4 25 12x6, 15x3 7.50 50 Mt.
5 30 16x3, 18x6, 20x3 7.50 50 Mt.
6 35 20x6, 25x3 7.70 50 Mt.
7 41 25x6, 25x9 8.90 50 Mt.
8 48 25x12, 30x6, 30x10 10.40 50 Mt.
9 55 30x12, 38x6 11.60 50 Mt.
10 61 38x12, 40x6, 40x10 13.20 50 Mt.
11 73 50x6 15.80 50 Mt.
12 81 50x10, 50x12 17.20 50 Mt.
13 93 75x6 19.90 50 Mt.
14 103 75x12 22.50 50 Mt.
15 110 90x6, 90x12 23.70 50 Mt.
16 128 100x6, 100x9 28.30 50 Mt.
17 140 100x12 32.00 50 Mt.
18 170 125x6, 125x12 38.20 50 Mt.
19 190 150x6, 150x10, 150x12 44.00 50 Mt.
20 210 175x6, 175x10, 175x12 51.00 50 Mt.
21 230 200x12 56.00 50 Mt.
All Dimensions are in MM.
Material : PVC.
All Products are CE certified.
